    Kaw Dam Bridge Bearing Replacement Underway [Image 4 of 4]

    Issued by: on
    VIRIN:
    Date Created:
    City:
    State:
    Country:
    The image shows a close-up of a concrete surface, likely under a bridge or overpass, featuring graffiti spray-painted in bright green and dark grey/black. The graffiti appears to depict a stylized design with curved, leaf-like or flame-like green shapes outlined in dark paint. Additional smaller pink/red text markings are visible in the lower right corner.

    OKLAHOMA, UNITED STATES

    08.19.2026

    Photo by Stacey Reese

    U.S. Army Corps of Engineers, Tulsa District

    Green paint identifies scanning locations on a pier cap along the Kaw Bridge catwalk where light detection and ranging (lidar) technology was used for bearing replacement work at Kaw Dam near Kaw City, Oklahoma, Aug. 20, 2026.

    Lidar technology enabled crews to locate reinforcing steel within the concrete. The scanning was completed before bearing replacement work began. All 32 original rocker bearings are being replaced with new elastomeric bearings. Elastomeric bearings have a longer life expectancy than the original rocker bearings and contain no moving metal parts, making them virtually maintenance-free, more resistant to corrosion and better able to absorb shocks and vibrations. (U.S. Army photo by Stacey Reese)
