    Kaw Dam Bridge Bearing Replacement Underway [Image 1 of 4]

    Issued by: on
    VIRIN:
    Date Created:
    City:
    State:
    Country:
    The image shows a close-up view of a bridge bearing assembly, specifically an elastomeric bearing pad supporting a steel girder on a concrete abutment or pier. The bearing pad is marked 'A1 559' and sits beneath a steel sole plate with a visible anchor bolt and nut. Surface rust and minor deterioration are visible on the steel girder components.

    OKLAHOMA, UNITED STATES

    08.19.2026

    Photo by Stacey Reese

    U.S. Army Corps of Engineers, Tulsa District

    A newly installed elastomeric bearing supports a bridge span at Kaw Dam near Kaw City, Oklahoma, Aug. 20, 2026.

    The bearing, secured with a new anchor bolt, replaces an original rocker bearing as part of a project to replace all 32 bridge bearings. Elastomeric bearings have a longer life expectancy than the original rocker bearings and contain no moving metal parts, making them virtually maintenance-free, more resistant to corrosion and better able to absorb shocks and vibrations. (U.S. Army photo by Stacey Reese)
