The Jet Blast Deflector Conveyor tool was developed by the Rapid Prototype Center in partnership with the toolmakers, Code 930, and Code 263 in order to lift and rotate the shafts in the jet blast deflector operating gear to eliminate the need for extensive rigging requirements as well as removing the need to cut access points to remove the fixture.
| Date Taken: | 09.10.2025 |
| Date Posted: | 11.17.2025 13:34 |
| Photo ID: | 9392333 |
| VIRIN: | 250910-N-UC087-9799 |
| Resolution: | 5949x3966 |
| Size: | 3.11 MB |
| Location: | PORTSMOUTH, VIRGINIA, US |
| Web Views: | 19 |
| Downloads: | 1 |
This work, Eye On Innovation: Rapid Prototype Center’s Jet Blast Deflector Conveyor Tool Brings Huge Savings to America’s Shipyard and the Navy [Image 5 of 5], by PO1 Christian Victor Bautista, identified by DVIDS, must comply with the restrictions shown on https://www.dvidshub.net/about/copyright.
