Lower Granite Dam
This congressionally authorized project consists of Lower Granite Dam, navigation lock, powerhouse, a fish ladder and associated facilities. The project provides hydroelectric generation, navigation, recreation and incidental irrigation. The dam, located at the upstream end of Lake Bryan, is about 3,200 feet long with an effective height of 100 feet. The dam is a concrete gravity type, with an earthfill right abutment embankment. It includes a navigation lock with clear dimensions of 86 by 674 feet; and an eight-bay spillway that is 512 feet long, with eight 50-foot by 60.5-foot radial gates.
