In order to non-invasively measure the unsteady, 3D velocity field of a jet plume from a stationary aircraft engine, Nov. 18, 2021, a laser beam is redirected and spread into a wider plane as it crosses behind the engine at the Propulsion Research Facility operated by Arnold Engineering Development Complex on the campus of the University of Tennessee Space Institute in Tullahoma, Tenn. Cameras are then aimed at a 45-degree angle to the laser plane to observe the scattered laser light from soot particles in the exhaust and measure their velocity. (U.S. Air Force photo by Jill Pickett)
| Date Taken: | 11.18.2021 |
| Date Posted: | 01.28.2022 11:56 |
| Photo ID: | 7026314 |
| VIRIN: | 211118-F-KN521-1013 |
| Resolution: | 7952x6288 |
| Size: | 12.24 MB |
| Location: | ARNOLD AFB, TENNESSEE, US |
| Web Views: | 18 |
| Downloads: | 3 |
This work, AEDC engineers assist with SBIR effort researching noise reduction of aircraft engines [Image 7 of 7], by Jill Pickett, identified by DVIDS, must comply with the restrictions shown on https://www.dvidshub.net/about/copyright.
AEDC engineers assist with SBIR effort researching noise reduction of aircraft engines
