    18th EMS showcases 3D technology [Image 1 of 7]

    Issued by: on
    VIRIN:
    Date Created:
    City:
    State:
    Country:
    Two military personnel in camouflage uniforms and black face masks are engaged in a discussion or briefing inside what appears to be a military maintenance or fabrication facility. One individual is gesturing while holding an object, suggesting a demonstration or explanation is taking place. Additional personnel are visible in the foreground observing the interaction.

    KADENA AIR BASE, OKINAWA, JAPAN

    05.07.2021

    Photo by Airman 1st Class Anna Nolte

    18th Wing

    Senior Airman Nicholas McConnell, left, an aircraft metals technology journeyman from the 18th Equipment Maintenance Squadron, observes while Senior Airman Dominick Ferneding, right, an aircraft metals technology journeyman from the 18th EMS, explains the equipment for a 3D technology demonstration at Kadena Air Base, Japan, May 7, 2021. The FaroArm is a 3D laser scanner which allows them to create a digital 3D model in a few days, a process that might have taken a month in the past. (U.S. Air Force photo by Airman 1st Class Anna Nolte)

    IMAGE INFO

    Date Taken: 05.07.2021
    Date Posted: 05.13.2021 03:00
    Photo ID: 6642506
    VIRIN: 210507-F-ZJ963-1009
    Resolution: 5906x3937
    Size: 1.27 MB
    Location: KADENA AIR BASE, OKINAWA, JP
    Web Views: 34
    Downloads: 5

    PUBLIC DOMAIN

    This work, 18th EMS showcases 3D technology [Image 7 of 7], by SrA Anna Nolte, identified by DVIDS, must comply with the restrictions shown on https://www.dvidshub.net/about/copyright.

    GALLERY

    Two military personnel in camouflage uniforms and black face masks are engaged in a discussion or briefing inside what appears to be a military maintenance or fabrication facility. One individual is gesturing while holding an object, suggesting a demonstration or explanation is taking place. Additional personnel are visible in the foreground observing the interaction.
    A US Air Force service member in OCP (Operational Camouflage Pattern) uniform is using a FARO handheld measurement device, likely a FARO Quantum arm probe, to inspect or measure a metallic component on a work surface. The setting appears to be a maintenance or metrology shop environment. The activity suggests precision measurement or quality control work on aircraft or equipment parts.
    A U.S. Air Force airman in OCP (Operational Camouflage Pattern) uniform and black face mask operates a FARO portable coordinate measuring arm in what appears to be a fabrication or metrology lab. The airman is using the FARO arm to measure or inspect a component mounted on a FARO granite surface plate. The setting includes various manufacturing and 3D printing equipment visible in the background.
    Two individuals, one in military camouflage uniform and one in civilian clothing, are reviewing a 3D CAD model displayed on a computer monitor. The person in uniform is seated and pointing at the screen, appearing to explain or discuss the design with the standing civilian. Both individuals are wearing face masks, suggesting this was taken during a period of COVID-19 precautions.
    Two U.S. Air Force personnel in OCP (Operational Camouflage Pattern) uniforms and black face masks are working with a FARO Design measurement arm in what appears to be a maintenance or fabrication facility. Both individuals are focused on operating or adjusting the blue articulated coordinate measuring device mounted on a workbench. The setting is an industrial workshop environment with visible ventilation ducts and overhead infrastructure.
    A military personnel member in MultiCam/OCP camouflage uniform is having their forearm and hand scanned using a handheld 3D scanner beneath a 'Design Scan' branded arm/gantry system. A blue laser line is visible projecting onto the subject's wrist area, indicating an active scanning process. This appears to be a medical or equipment-fitting application, possibly for custom prosthetics, orthotics, or ergonomic equipment design.
    A military service member in camouflage uniform and face mask is working at a computer workstation, viewing a 3D scan of a human hand rendered in blue on the monitor. The software displayed appears to be a 3D scanning or CAD application, likely used for prosthetics, medical, or manufacturing purposes. The setting appears to be a technical lab or workshop environment.
